HMPL is the leading manufacturer, supplier and exporter of Dialysis Kits From India.

Hemodialysis is a process that filters endogenous and exogenous wastes from your blood. The Arrow+ Hemodialysis Catheter Set offers an Innovative set consisting of multiple lumen (Single, Double & Triple) MARK Hemodialysis Catheter & other supportive consumables for blood purification.

  • X-ray opaque polyurethane catheter with injection cap
  • J/St tip stainless steel or nitinol guide wire with advancer & extra soft tip
  • Easy to use 11# scalpel blade
  • Long tapered tip dilator with stopper to avoid over insertion
  • Introducer needle that offers Quick & smooth insertion
  • Soft and easy to use Extension Line Clamp
  • Disposable Syringe 5ml with extra clear visibility
  • Guiding Syringes 5ml allows insertion through syringe plunger
  • Wound Dressing Pad
  • Catheter Protector Pouch
  • 4 Drape Sheet

The MARK Hemodialysis Catheter provides optimal flow rates up to 350 cc/min even at lower arterial pressure. Arrow+ Hemodialysis Catheter is made up of radiopaque polyurethane, anti-kinking material that offers flawless insertion and smooth, flexible tip, clearly visible under the X-ray scan. Side slots are 2.5cm far from the tip end and offer reduced recirculation and wall-suction. Laser cut Side holes also Minimizes risk of in vitro clot formation during procedure. Tapered distal arterial tip facilitates blood flow even if the catheter tip sets against the blood vessel’s epithelium and minimizes positional occlusion. Silicone Extension Tube facilitates patient’s comfort, and it will not crimp over the period that also offers clear visualization of fluids. Scaled J-tip guidewires that protects vessel inner wall and facilitate in knowing the insertion depth of side wire. Arrow+ having Infection preventive Heparin Injection Cap. Long tapered tip dilators with stopper to avoid over insertion.

  • Used as a temporary access for dialysis or transfusion
  • Continuous or discontinuous venous infusion
  • Transfusion of blood and its products
  • Blood sampling
Product Code Lumen Catheter Size Catheter Length (cm) Dilator Guidewire Shape of Extension Tube
ARS0705S Single Lumen 7Fr 5 8F×10cm 0.035"×50cm Straight
ARS0705C Curved
ARS0708S Single Lumen 7Fr 8 8F×10cm 0.035"×50cm Straight
ARS0708C Curved
ARS0710S Single Lumen 7Fr 10 8F×10cm 0.035"×50cm Straight
ARS0710C Curved
ARS0713S Single Lumen 7Fr 13 8F×10cm 0.035"×50cm Straight
ARS0713C Curved
ARS0716S Single Lumen 7Fr 16 8F×10cm 0.035"×50cm Straight
ARS0716C Curved
ARS0720S Single Lumen 7Fr 20 8F×10cm 0.035"×60cm Straight
ARS0720C Curved
ARS0805S Single Lumen 8Fr 5 9F×10cm 0.038"×50cm Straight
ARS0805C Curved
ARS0808S Single Lumen 8Fr 8 9F×10cm 0.038"×50cm Straight
ARS0808C Curved
ARS0810S Single Lumen 8Fr 10 9F×10cm 0.038"×50cm Straight
ARS0810C Curved
ARS0813S Single Lumen 8Fr 13 9F×10cm 0.038"×50cm Straight
ARS0813C Curved
ARS0816S Single Lumen 8Fr 16 9F×10cm 0.038"×50cm Straight
ARS0816C Curved
ARS0820S Single Lumen 8Fr 20 9F×10cm 0.038"×60cm Straight
ARS0820C Curved
Product Code Lumen Catheter Size Catheter Length(cm) Dilator Guidewire Shape of Extension Tube
MKT1213S Triple Lumen 12Fr 13 12F×15cm 0.038"×50cm Straight
MKT1213C Curved
MKT1216S Triple Lumen 12Fr 16 12F×15cm 0.038"×50cm Straight
MKT1216C Curved
MKT1220S Triple Lumen 12Fr 20 12F×15cm 0.038"×60cm Straight
MKT1220C Curved

  • The product codes in this chart are for HC kits with straight introducer needle configuration.
  • HC kits with Y-shaped introducer needle configuration are also available upon discussion. The product code of HC kit with Y-shaped introducer needle configuration. Before you order, please clarify which configuration you request, either straight or Y-shaped introducer needle.
  • Pediatric types of HC include double lumen 6.5Fr and 8.5Fr.
  • Adult types of HC include single lumen 7Fr, 8Fr; double lumen 11.5Fr, 12Fr, 14Fr and triple lumen 12Fr.
  • "MK" in the product code means ``with soft tip”.
  • Pre-curved catheter is available for adult type in double lumen 11.5Fr, 12Fr, 14Fr.

Note: Pre-curve Catheter (Double Lumen) also available, that facilitates more comfort to the patients.
